Automotive Panel Mold

A single-cavity injection mould for an automotive interior panel, built on a standard mould base and nitrided for wear resistance. DFM analysis is provided before the steel is cut.

Automotive panel mould, assembled
Automotive panel mould, core side
Automotive panel mould, cavity side
Automotive panel mould, detail of the machined surface

Specifications

CategoryMould / tooling
IndustryAutomotive
MaterialMould steel NAK80
Colour—
Dimensions400 × 350 × 385 mm
WeightApprox. 337 kg (complete tool)
Surface finishNitriding
Cavities1 × 1
ProcessCNC machining + EDM + assembly
MOQ1 set
Sampling lead time30 days
Production lead time21 days

Lead times above are for repeat orders. New tooling projects are quoted per project, with the schedule confirmed in writing before the steel is cut. No prices are listed on this site: send us your drawing and we quote tooling and piece price separately.

Request a quote
